PTFE Lined Tubing
PTFE-kab tubing kuj tau siv nyab xeeb los thauj cov corrosive, siab -purity, thiab siab - cov kua dej kub. Cov tubing sab nrauv yog ua los ntawm cov hlau, thaum lub hauv ob sab phlu yog PTFE, ua rau lub neej ua haujlwm ntev. Lub puab nto ntawm PTFE thiab nws cov kab mob sib kis-dawb khiav ua PTFE-kab tubing yog ib qho kev daws teeb meem zoo tshaj plaws rau kev lag luam thiab cov txheej txheem kev siv qhov kev ntseeg siab thiab kev huv yog qhov tseem ceeb.
Khoom Specifications
Tsis zoo siab: Tsim raws li qhov sib txawv ambient tej yam kev mob ntawm cov neeg siv.
|
Specification |
General PTFE thickness thiab tsis zoo siab-kuj |
Lub thickness ntawm PTFE phab ntsa yuav tsum tiv taus -0.1MPa siab thaum qhov kub thiab txias yog tsawg dua 120 degree |
|
|
DN 25 |
2 hli |
-0.08 Mpa |
3mm (L Tsawg dua lossis sib npaug li 3000mm) |
|
DN 32 |
2 hli |
-0.075 Mpa |
3mm (L Tsawg dua lossis sib npaug li 3000mm) |
|
DN40 |
2.5 hli |
-0.07 Mpa |
4mm (L Tsawg dua lossis sib npaug li 3000mm) |
|
DN 50 |
2.5 hli |
-0.06 Mpa |
5mm (L Tsawg dua lossis sib npaug rau 3000mm) |
|
DN 65 |
2.5 hli |
-0.05 Mpa |
8mm (L Tsawg dua lossis sib npaug li 10000mm) |
|
DN80 ua |
3mm ib |
-0.05 Mpa |
10mm (L Tsawg dua lossis sib npaug li 10000mm) |
|
DN100 |
3mm ib |
-0.04Mpa |
13mm (L Tsawg dua lossis sib npaug li 10000mm) |
|
DN125 |
4mm ib |
-0.03 Mpa |
13mm (L Tsawg dua lossis sib npaug li 10000mm) |
|
DN150 |
4mm ib |
-0.025 Mpa |
13mm (L Tsawg dua lossis sib npaug li 10000mm) |
|
DN200 |
5mm ua |
-0.02 Mpa |
15mm (L Tsawg dua lossis sib npaug li 10000mm) |
Khoom zoo
Tshuaj tiv thaiv
PTFE hauv ob sab phlu tuaj yeem muaj zog acids, alkalis, kuab tshuaj, thiab tshuaj corrosive.
High Purity thiab Pollution -Dawb
Qhov du, tsis yog - nplaum sab hauv qhov chaw tiv thaiv kev tsim cov nplai, ua kom cov khoom xa tawm huv.
Kev kub siab dav
Txhim khu kev ua haujlwm hauv ob qho tib si qis - thiab siab - qhov kub thiab txias.
Kev sib txhuam qis
Txo qhov poob siab thiab txhim kho qhov system efficiency.
Ntxiv -Long Service Life
Resistant rau corrosion, laus, thiab tshuaj degradation.
Kev cai tsim khoom
Qhov ntau thiab tsawg, kev ntsuas siab, thiab cov qauv tuaj yeem hloov kho raws li koj qhov kev thov.
Cov khoom siv
PTFE Lined Tubing yog dav siv hauv kev lag luam uas xav tau kev tiv thaiv corrosion thiab siab huv cov qauv, suav nrog:
- Kev siv tshuaj thiab petrochemical
- Pharmaceutical thiab biotechnology kev lag luam
- Kev ua zaub mov thiab dej haus
- Semiconductor thiab electronics manufacturing
- Kev kho dej thiab ib puag ncig engineering
- Tshiab zog thiab roj teeb ntau lawm
Khoom Zoo
Peb nkag siab tias cov khoom lag luam tsis zoo tsuas yog ua rau ib qho - lub sijhawm ua lag luam, thaum tsuas yog cov khoom siab - cov khoom zoo tuaj yeem tsim kev sib koom ua lag luam ntev -. Tongtong ua raws li kev tswj hwm nruj kom ntseeg tau tias qhov zoo ntawm nws cov PTFE- cov kav dej nyob hauv ib puag ncig, kev ua tau zoo yog txhim khu kev qha, thiab nws ua tau raws li kev lag luam thiab cov qauv thoob ntiaj teb.
Cim npe nrov: Tuam Tshoj PTFE lined tubing manufacturers, lwm tus neeg, Hoobkas
